Dongguan Yixin Qingjiang Machinery Manufacturing Co., Ltd.

AS6015-6/8

Flat-Top Tower Crane

Topless cranes
  • Jib Length: 60 m
  • Max. Lifting Capacity: 6/8 t
  • Jib-End Load: 1.5 t

The flat-top tower crane is highly employed in building projects for quick transportation of different building materials and equipment, thereby improving construction efficiency. The flat-top tower crane presents higher lifting efficiency, precision, and safety. Comparing with conventional approaches, it drastically lowers project times.

At AISUN you get: custom made tower cranes (appearance, size and others), 24 Hour dedicated customer service, installation guide and training, fault diagnosis, connection with local partners, comprehensive support and tracking of your needs. Contact us and we will sort out the best solution for your project.
Inquiry
Download Brochure
  • Configuration
  • Components
  • Features
  • FAQs

Key Parameters

Model Free Standing Height (m) Anchoring Height (m) Max. Lifting Capacity (t) Tower Section Size (m) Jib Length (m) Max. Lifting Moment (kN.m)
AS6015 46.5 220 6/8 1.8×1.8×2.8 60 1496
Configuration Parameters
  Unit Max. Lifting Capacity 6t Max. Lifting Capacity 8t
Hoisting Gear Speed m/min 0～80(a=2) 0～80(a=2)
Power kW 24 30
Trolley Travel Gear Speed m/min 0～55 0～55
Power kW 4 4
Slewing Gear Speed r/min 0～0.6 0～0.6
Power kW 4.0×2 4.0×2
Total Power kW 36 42
Power Supply 380V(±10%)/50HZ
Tower Crane Components
Flat-Top Tower Cranes
  • 1Crane Cabin
  • 2Working Platform & Guardrails
  • 3Standard Tower Section
  • 4Slewing Assembly
  • 5Tower Crane Trolley
  • 6Crane Hook Block
  • 7Hoist Gear Assembly
    • Flat-Top Tower Cranes
      1Crane Cabin

      Designed with your crane operator’s comfort in mind, enjoy a broad perspective with big glass windows and user-friendly elements including a fire extinguisher, air conditioning, wipers, and coat hooks.

    • Flat-Top Tower Cranes
      2Working Platform & Guardrails

      Hot-dip galvanized guardrails, ideal for whatever environment you come across, provide exceptional corrosion resistance and weatherability.

    • Flat-Top Tower Cranes
      3Standard Tower Section

      Designed with high-strength steel construction for great load-bearing capability, wind resistance, and corrosion resistance guarantees your crane functions remarkably under all conditions.

    • Flat-Top Tower Cranes
      4Slewing Assembly

      Provides outstanding stability, low maintenance, quick transportation, and installation for your rigorous operation requirements.

    • Flat-Top Tower Cranes
      5Tower Crane Trolley

      Using a trolley that runs along the jib track will maximize your operating range and give efficiency and flexibility for lifting.

    • Flat-Top Tower Cranes
      6Crane Hook Block

      Built of high-strength steel hook block with outstanding load capacity, corrosion resistance, and longevity, giving you confidence in every lift.

    • Flat-Top Tower Cranes
      7Hoist Gear Assembly

      Using a hoist gear assembly with high rope capacity will help you to achieve effective lifting and provide you better stability and control during operations.

Key Features
    • Flat-Top Tower Cranes

      Safety and Reliability

      • The load limiter and lifting torque limiter are two overload prevention devices that help to prevent tower crane overload and overtorque.
      • Double amplitude (stroke) limiters and triple lifting height limiters help you monitor and control lifting height, therefore avoiding crane collisions.
      • Enjoy the security of a frequency converter in the electric control system for sophisticated anti-drop hook detection, which guarantees smooth lifting and stopping for greater efficiency and safety.
      • Large platforms and inclined ladders on our tower crane help to prevent falls.
      • Experience stability during operations. Jacking is done without slewing, ensuring balance without tilting during construction, enabling mounting and dismounting without falling, and preventing unintended slewing.
    • Flat-Top Tower Cranes

      Upgraded Coating

      • With our double-component paint on structural components, you are guaranteed a rust-free structure for five years.
      • Components like platforms, ladders, and railings undergo hot-dip galvanizing to ensure you get lifetime rust and corrosion prevention as well as anti-slip features.
      • With automotive-grade spot welding and electrophoresis technology, our crane's operator's cab is created in a single stamping process, letting you enjoy no rust for a decade.
    • Flat-Top Tower Cranes

      Superior Operability

      • The frequency conversion slewing technology will enable you to turn on and off with no vibrations and zero swing during stops, so producing instantaneous response.
      • With millimeter-level slow-speed positioning and a minimum of 5mm/s, which allows exact control, precision is right at your hand. The system reacts right away and the operator can employ jogging control on the handle.
      • With the sophisticated detection of the electric control system, your lifting speed adaptably changes: heavier loads hoist slower, lighter loads lift faster.
      • During crane slewing, the system prevents the jib and hoisting wire rope from swaying side-to-side. It stops jib and hoisting wire rope from forward and backward swaying during luffing operations. Should fast stopping be needed during slewing, the operator can rapidly stop the crane's rotation by means of reverse handle operation.
    • Flat-Top Tower Cranes

      User-Friendliness

      • Integrated assembly in the factory simplifies your logistics by means of professional loading and unloading plans, therefore minimizing packaging units and transportation vehicles.
      • Using maintenance-free lubricating oil in the hoisting mechanism will help to reduce maintenance and workload.
      • Increase efficiency and save time with our pre-calibrated electronic load limiters ready for use without field calibration on-site.
      • Enjoy great adaptability with counterweights; models in their series such as 6013, 6513, 6515 have interchangeable counterweights within their series. The same holds for 7521 and 7527.
FAQs

A tower crane is a tall, self-elevating lifting equipment, mainly used in the construction of high-rise buildings, capable of handling materials in both vertical and horizontal directions.

Regular inspections and maintenance are necessary, including lubricating moving parts, inspecting and replacing worn parts, ensuring that safety devices are functioning properly, etc. We have a professional repair team to provide maintenance support and service.

Yes, we provide professional remote training services for tower crane operation and maintenance to ensure your operators can use the equipment safely and effectively.
